ISG/ISW Inline Pumps
The ISG pipeline pump is a type of pump featuring a vertical structure with identical inlet and outlet pipe diameters, facilitating convenient installation and maintenance without the need to dismantle the piping system. Primarily utilized in industrial and municipal water supply and drainage applications, it operates within environmental conditions requiring an ambient temperature of less than 40°C and a relative humidity of less than 95%. Its design principle involves a clever combination and manufacturing process based upon the foundation of standard vertical pumps.
| Features |
|---|
| The pump features a vertical structure, with the inlet and outlet having identical diameters and being situated on the same centerline. |
| It has a compact and attractive appearance, a small footprint, and low construction costs. |
| The pump and motor bearing configuration is well-designed. |
| Installation and maintenance are convenient, requiring no dismantling of the piping system. |
| Pumps can be connected in series according to usage requirements, i.e., flow rate and head needs. |
| Depending on the requirements of the piping layout, the pump can be installed in either a vertical or horizontal orientation. |
| Technical Parameters | |
|---|---|
| Product Name | ISW/ISG Pipeline Centrifugal Pump |
| Pump Structure | Centrifugal Clear Water Pump |
| Rated Flow Rate |
1.1–1450 m³/h |
| Rated Head |
7–153m |
| Power Range |
0.75–185 kW |
| Rated Voltage |
AC 380V /660V 50Hz |
| Material | High-Chromium Wear-Resistant Alloy |
| Sealing Type | Mechanical Seal |
| Applicable Media | Slurry, mineral pulp, sand-and-silt mixture |
| Installation Method | Submersible Installation (Fixed / Mobile) |
Strict inspection of composition and dimensions ensures stability from the source.
Key components like impellers and shafts are CNC machined for high consistency.
Coating and heat treatment tailored for water, sewage, slurry, and chemical environments.
Assembly by SOP (Standard Operating Procedure) ensures minimized vibration and leak-proof performance.
Full testing of head, flow, and efficiency before delivery for complete traceability.
Customized wooden crates or pallets with moisture-proof measures for long-distance transport.
Investing in equipment and training to ensure stable, high-quality international delivery.
Providing precautions and connection advice via documentation or video support for correct startup.
Maintenance advice on lubrication, sealing, and periodic inspections to extend equipment life.
Long-term supply of common spare parts and selection assistance from our engineering team.
Rapid analysis and solutions for any abnormalities found during use.
Regular check-ins on equipment status to provide optimization suggestions.
Committed to a professional, stable, and responsible service system for global partners.
-
